MARSIDE Series

DG2K-Solid Colors

Release time:2016/7/11 17:16:07 Click volume:
Product Name/Model:DG2K-Solid Colors
Characteristic:DG2K Solid Colors, high gloss and build, good performance of leveling property,
easy construction, excellent pretective and coveraging power, long lasting bright color.
Mainly applies to intermediate cars, MPV and bus.
Substrates
Well-Sanded, Completely dried and good existing finishes as bellow:
A original paint B. Old paint firm C. 1K or 2k primer
Surface Cleaning
Wash by warm soap, remove wax, silicon and other contaminations with degreaser, sanding
with P800-P1000, wash with clean water then keep dry; again with degreaser.
Mixing Ratio
DG2K Solid Colors
Hardener
Thinner
2
1
0.2-0.4
<15℃
DG2K Solid Colors
MSH1021 Fast Hardener
90 Fast Thinner
15-30℃
DG2K Solid Colors
MSH1020 Standard Hardener
91 Standard Thinner
>30℃
DG2K Solid Colors
MSH1022 Slow Hardener
92 Slow Thinner
Spray Viscosity
16-19s to drop off, in 4# viscosity cup, at 25°C,
Pot-life
At 25°C
2 hours with fast hardener.
4 hours with standard or slow hardener.
ReTreatment
There are particles or runs after spray, sand affected area with P2000 sand paper after
thorough drying, then polish to solve the problem.
Spray Gun Set Up
Gravity Feed: 1.2-1.5mm 3-5kg/cm 2
Suction Feed: 1.4-1.6mm 3-5kg/cm 2
Spray Technology
Coats&Thickness: 2-3 coats, total 35-50um
Flash-Off Time: At 25°C, 5-10 minutes between two coats,
Air-Drying Time: Allow 10-15 minutes air drying time before force drying
Drying Time
Temperature
Dust Free
Tack Free
Dry To Handle
Dry To Test
+25°C
40 minutes
2 hours
9 hours
6 Days
+70°C
5 minutes
10 minutes
25 minutes
50 Minutes
Shelf Life
2 years in original sealed can, cool and dry place at 25℃.
Package
1L×12 or 3.75L×4

Note:
1. The substrate must be cleaned and sanded before spray, wet sanding P800-1000 and then dry.
2. At ambient temperature higher than 30℃, add appropriate Retarder Solvent into thinner to
avoid blushing. For more details, please refer to technical data sheet of Retarder Solvent.
3. The products mixed with hardener should be used up soon and can not be restore for future use;
clean equipments immediately with thinner after application, otherwise it is very difficult to be
cleaned after dry.
